The ZHENGXI Adjustable Manual Voltage Regulator Transformer is a high-efficiency, manually adjustable autotransformer that allows precise voltage regulation. Designed with a toroidal transformer and a carbon brush, it provides stable and distortion-free voltage output for various industrial and commercial applications.
This three-phase voltage regulator transformer offers an adjustable output range from 0V to 430V, making it suitable for applications requiring customized voltage control. It features a compact design, high efficiency (95%), and a durable structure for reliable long-term operation.
With its robust build and superior performance, this transformer ensures safe and precise voltage control, making it indispensable for laboratories, workshops, production lines, and household applications.
Key Features
- Adjustable Voltage: Freely adjustable between 0V to 430V for precise control.
- High Efficiency: Maintains over 90% efficiency for energy savings.
- Stable Performance: Provides distortion-free voltage output.
- Compact & Lightweight: Easy to transport and install.
- Reliable & Durable: Designed for long-term operation.
- Heavy-Duty Construction: Ensures a long service life and consistent performance.
- User-Friendly Operation: Simple manual adjustment for effortless voltage control.
- Wide Compatibility: Suitable for various electrical devices and machinery.
- Multiple Applications: Ideal for use in chemical, metallurgy, instrumentation, machinery, and household appliances.
Applications
This adjustable transformer is widely used in industries such as:
- Manufacturing (machinery, automation systems, assembly lines)
- Chemical & Metallurgy (precision equipment, research labs, electrochemical processes)
- Public Equipment (power supply control, industrial testing, voltage stabilization)
- Household Appliances (voltage regulation, power supply conditioning, DIY projects)
- Medical & Laboratory Equipment (precise power supply for sensitive instruments)
- Educational Institutions & Research Centers (for experiments and controlled voltage applications)
- Lighting Systems & Electrical Testing (smooth voltage control for lighting and test equipment)
How It Works
The transformer operates based on an autotransformer design, featuring a toroidal coil and a carbon brush. When the carbon brush rotates along the coil’s surface, it adjusts the contact position, altering the coil turn ratio and thereby controlling the voltage output. This simple yet highly effective mechanism ensures smooth and stable voltage regulation without waveform distortion.
| Model | TSGC2 Series |
|---|---|
| Core Type | Shell-type Transformer |
| Cooling Method | Natural Cooling |
| Winding Type | Separated Winding Transformer |
| Certification | ISO9001, CE |
| Usage | Three-Phase Transformer |
| Frequency | 50Hz / 60Hz |
| Output Voltage | 0-430V ±10% (customizable) |
| Input Voltage | 380V ±10% |
| Efficiency | >90% |
| Waveform Distortion | None |
| Electrical Strength | 1500V / 1 min |
| Insulation Resistance | Single phase >5MΩ, Three phase >2MΩ |
| Shape of Core | Ring |
| Brand | ZHENGXI |
| Model Number | TDGC2-15kVA |
| Type | Contact Type |
| Gross Weight | 60.000kg |
| Package Size | 60x60x60 cm |
| OEM/ODM | Yes |
| Transport Package | Export Standard Packing |
| HS Code | 8504401990 |
| Origin | Zhejiang, China |
Why Choose ZHENGXI Transformers?
At ZHENGXI, we prioritize quality, performance, and customer satisfaction. Our transformers are designed to meet the highest industry standards, ensuring stability, durability, and efficiency for all your power regulation needs.
Our Advantages:
- Certified Quality: ISO9001 & CE certification for reliability.
- Customizable Solutions: Voltage and design can be tailored to your needs.
- Expert Support: Professional technical assistance and after-sales service.
- Innovative Design: Engineered for efficiency and easy operation.
- Competitive Pricing: High-quality transformers at affordable rates.
- Global Delivery: Fast and secure shipping worldwide.
Order Now
For bulk orders or custom specifications, contact us today! Experience efficient, stable, and adjustable voltage regulation with ZHENGXI Transformers.
We offer OEM & ODM services, ensuring that our transformers meet your exact requirements. Don’t compromise on quality—choose ZHENGXI for unparalleled performance and reliability in power regulation.
